1. Music parameter balance: 7

2.Music to main output high pass filter:

12dB/24dB(0Hz-303Hz)

★Primary output

(Working mode: Sing/dance(automatic/

manual), contains all parameters except

pressure limit, delay, and mute)

2.MIC direct sound electrical level: 0-

200%

3.High-pass filter: 12dB,Q0.4-

1.5/Bessel 24dB/Butterworth 24dB/Link

Microphones

1.4 Microphones FBE modes: OFF,1,2,3

2.Microphones pressure limit function

3.1 5 Microphones parameter balance

1.Music electricallevel: 0-200%

2.Direct sound electrical level: 0-200%

3. Echo electrical level: 0-200%

4.Reverberation electrical level: 0- 200%

Riley 24dB/USER 12dB/USER

24dB(0Hz- -303Hz)

4.L ow-pass filter: 12dB,Q 0.4-

1.5/Bessel 24dB/Butterworth 24dB/Link

Echo effects

1. Echo low-pass filter: 5.99Hz-20.6KHz

2. Echo high-pass filter: 0Hz-1000Hz

3. Echo parameter balance: 3

4. Echo electrical level: 0-100%

5. Echo direct sound level: 0-1 00%

6. Echo pre delay: 0-500ms

7. Echo right channel pre delay:

0-±50%(Relative to left channel)

8. Echo total pre delay: 0-500ms

9. Echo right channel delay:

0- 50%(Relative toleft channel echo

delay time)

10. Echo repeat: 0-90%

★Reverberation

5.5 Music parameter balance

6.Compression limiter

7.Left channel delay: 0-50ms

8. Right channel delay: 0-50ms

9.Left channel mute function

10. Right channel mute function

★Center output

(Working mode: Sing/dance(automatic/

manual), contains all parameters except

pressure limit, delay, and mute)

1.Music electrical level: 0- -200%

2.Direct sound electrical level: 0-200%

3. Echo electrical level: 0-200%

4. Reverberation electrical level: 0-200%

5. High-pass filter: 0Hz-303Hz

Riley 24dB/ USER 12dB/USER

24dB(0Hz- -303Hz)

5.3 Parameter balance

6.Compression limiter

7.Delay: 0-50ms

8.Mute function

★Rear output

(Working mode: Sing/dance(automatic/

manual), contains all parameters except

pressure limit, delay, and mute)

1.Music electricallevel: 0-200%

2.Direct sound electrical level: 0-200%

3. Echo electrical level: 0-200%

4.Reverberation electrical level: 0-200%

5.High-pass filter: 0Hz-303Hz .

6.3 Parameter balance

7.Compression limiter

8.Left channel delay: 0-50%

9. Right channel delay: 0- 50%

10.L eft channel mute: mute/un-mute

11. Right channel mute: mute/un-mute

1. Reverberation low- pass filter adjustable

range: 5.99Hz-20. 6KHz

2. Reverberation high-pass filter adjustable

range: 0Hz-1000Hz

3. Reverberation electrical level adjustable

range:1-1 00%

4. Reverberation direct sound adjustable

range: 0-100%

5. Echo pre delay adjustable range:

 0-200ms

6. Reverberation time adjustable range:

0-3000ms.

6.3 Parameter balance

7.Compression limiter

8. Delay: 0-50ms

9.Mute function

★Ultra low sound output

(Working mode: Sing/dance(automatic/

manual),contains all parameters except

pressure limit,delay ,and mute)

1.Music electrical level:0-400%
